2018 KTM 500 EXC-F

Dubbed as the King of the Mountains, the 2018 KTM 500 EXC-F bike has a fuel injected powerhouse that makes it the most compact and lightest 500 on the market. It also has a single overhead camshaft cylinder head that delivers ground breaking torque and power figures over the entire revolution range.  2018 KTM 500 EXC-F

Additionally, the design of the bike’s die-cast crankcases allows for minimal weight and centralized shaft configuration. This makes the engine short and compact, while contributing to an efficient centralization of masses. The engine covers also feature a solid surface structure, which reduces the wear caused by the rider’s boots. This way, your EXC-F will keep looking better longer.The KTM 500 EXC-F is fitted with a unique E-starter as standard, which is a clear advantage when it comes to crunch time in the heat of battle. A strong starter motor and a reliable lithium ion battery will fire up your 500 time and time again at the push of a button. In order to reduce weight to the minimum, there is no kick-starter system. You won’t miss it. If by any chance you do, just retrofit a KTM PowerParts replacement kit to get your kicks.

Bore (MM)95
CoolingLiquid
Displacement in CI31.1
StarterElectric
Valve ConfigurationSOHC
Compression Ratio11.8:1
Displacement in CC510.4
Engine TypeSingle-Cylinder
Stroke72
Numer Of Speeds6
Transmission TypeManual
Front TireContinental TKC 80 90/90 R21
Rear Tire Continental TKC 80 120/100 R18
Front Brake Diameter260
Rear Brake Diameter8.7
Front Brake TypeHydraulic Disc
Rear Brake TypeHydraulic Disc
Air AdjustableNo
Front Suspension TypeInverted Fork
Rear Adjustable Shock / Spring Pre-LoadYes
Seat Height (in)37.8
Front Suspension Brand NameWP
Rear Adjustable Rebound DampingYes
Rear Suspension Brand NameWP
Rear Suspension TypeTwin Sided Swing Arm
Fuel Capacity (gal)2.3
Manufacturer TypeEnduro
Wheelbase (in)58.3
Manufacturer CountryAustria
Dry Weight (lbs)240.3

In the last two decades, KTM’s off-road lineup has made the Austrians the brand to beat-from the desert to the trees to the rocks, and everywhere in between. KTM’s success is unprecedented, and bikes like the 2018 500 EXC-F have helped catapult the brand to the top of the podium on more occasions that we can count.
